- 32 parallel TTL-compatible outputs
mdec32-s firmware for controlling up to 32 general loads (solenoids, relays, lamps etc.) via external drivers:
- user selectable MIDI channel 1-16
- user selectable starting note
mdec32-sam firmware for controlling up to 16 Stop Action Magnet (SAM) switches via external drivers:
- user selectable MIDI channel 1-16
- user selectable output pulse length (range 100mS - 1.6S, step 100mS)
- fixed starting note (per request)
mdec32-pwm firmware for controlling up to 32 solenoid-driven percussive instruments via external drivers by single pulses or PWM signals depending on note velocity parameter:
- user selectable MIDI channel (1 out of 2)
- user selectable starting note (1 out of 8)
- user selectable velocity responce curve (1 out of 2)
- Pulse mode with selectable velocity-over-pulse-width mapping (1 out of 4)
- PWM mode with selectable velocity-over-duty-cycle mapping (1 out of 4)
- opto-insulated MIDI input
- MIDI Thru output
- recognizes MIDI Note On/NoteOff messages
- recognizes MIDI All Notes Off message
- supports Running Status and Zero-velocity
- recognizes and ignores System Exclusive and Realtimemessages as well
user options (on request):
- non-continuous note range
- responding to other MIDI messages instead of Note On/Note Off messages
